Header-Based Authentication

Overview

auth_type: "headers" attaches a fixed set of HTTP headers to every request Bifrost makes to the upstream MCP server. Use it for shared API keys, bearer tokens, or any other static authentication scheme. The same headers are used regardless of which caller (which VK, which user, which session) is hitting Bifrost — this is server-level auth. If you need each end-user to supply their own credentials, use Per-User Headers instead. This auth type is only valid for HTTP and SSE connections.

When to use

Shared API key the whole team uses
Internal MCP servers with a single bearer token
Custom header-based schemes (X-Tenant-ID, X-Region, etc.)
Anything where you’d add headers to a curl command

For per-user OAuth see OAuth 2.0 (admin authenticates once) or Per-User OAuth (each user authenticates).

Configuration

Header values support environment-variable references — use env.MY_VAR (or the UI’s env-var picker) to keep secrets out of the config file. Values are encrypted at rest when BIFROST_ENCRYPTION_KEY is set.

Web UI
API
config.json

Navigate to MCP Gateway in the sidebar
Click New MCP Server
Pick HTTP or SSE as the connection type, fill in the Connection URL
Set Auth Type to Headers
Add one row per header in the Headers table:
- Header name (e.g., Authorization, X-API-Key)
- Value — either a literal string or an environment-variable reference
Configure tool execution as needed
Click Create

MCP client form with Auth Type set to Headers and two static header rows configured

curl -X POST http://localhost:8080/api/mcp/client \
  -H "Content-Type: application/json" \
  -d '{
    "name": "web-search",
    "connection_type": "http",
    "connection_string": "https://mcp.example.com/mcp",
    "auth_type": "headers",
    "headers": {
      "Authorization": { "value": "Bearer your-api-key" },
      "X-Tenant-ID":   { "value": "acme-corp" }
    },
    "tools_to_execute": ["*"]
  }'

To reference an environment variable instead of a literal:

"Authorization": { "env_var": "MCP_API_KEY", "from_env": true }

{
  "mcp": {
    "client_configs": [
      {
        "name": "web-search",
        "connection_type": "http",
        "connection_string": "https://mcp.example.com/mcp",
        "auth_type": "headers",
        "headers": {
          "Authorization": { "value": "Bearer your-api-key" },
          "X-Tenant-ID":   { "value": "acme-corp" }
        },
        "tools_to_execute": ["*"]
      }
    ]
  }
}

Use { "env_var": "MCP_API_KEY", "from_env": true } for env references — same shape as the API tab.

Header lifecycle

At connect time, Bifrost opens a persistent transport with these headers attached. The same transport is reused for every tool call.
Authorization is treated specially — even if you set it via headers, the credential-store layer overrides it with the OAuth bearer for auth_type=oauth clients. For headers clients there is no override, so the literal value goes through.
Editing headers on an existing MCP client triggers a connection reset so the new headers take effect immediately. The MCP client’s connection_type, auth_type, and connection_string are immutable after creation.

Combining with `per_user_headers`

per_user_headers clients support a static admin headers section in addition to the per-user values. Use it for tenant headers or any constant that should accompany every per-user request. See Per-User Headers — Static admin headers.

Next Steps

OAuth 2.0 — when the upstream provides OAuth and you want token refresh
Per-User Headers — when each user has their own key
Connecting to MCP Servers — connection-type details
